Spindle And Bolster

Products Spindles:

hz-44, hz-55, hz-66, hz-68, hz-77, 20mm neck bearing spindle , 24mm neck bearing spindle, 28 mm neck bearing spindle.

For Machine:

For All Type Of Ring Twister Machine

For Process Type:

jute industries, tire cord yarn industries, nylon rope/ twine industries, fishnet industries , polyester , draw twisting , HDPE industries

Product Description

• Material : spindle blade : EN 31 (bearing steel), wharves : EN 24 / graded cast iron
• Spindle's wharves diameter up to 100 mm
• high quality , low vibration, long life
• supplies complete set with flange , nut , spindle lock
• manufacture spindle for ring diameter : 2.5", 3", 5", 5.5", 6", 6.5", 7", 7.5", 8", 8.5", 9", 10",12"
• we supplied spindle with specified insert as Texpart, Jaylaxmi.

Spindle Application

• Jaylaxmi vibration reduce up to 0.07 mm / sec
• Lift up to 480 mm
• Jaylaxmi reduce noise level to 110 DBA
• Long life
• We used standard bearing material with specified hardness.
• We can reduce the weight of spindle top part (new design)
• Short delivery time

Advantages

• Low noise & Power
• Speed: 3000 to 7000 rpm.
• We choose insert according to spindle's speed ,operating total weight and quality of yarn Can be supplied with any kind of brake system
• Dynamically balanced.
• 6 Stage Quality Checks to ensure exquisite quality system maintenance for superior performance.
• Made to fit your system and give higher and better performance index.

Technical Data
